HL130-Serie

HL130-Serie

HL130-Serie
Part Number Ih(A)
All
0.1
0.15
0.17
0.2
0.25
0.3
0.4
0.5
0.65
0.75
0.9
1.1
1.35
1.6
1.85
2
2.5
Vmax(Vdc)
All
130
Imax(A)
All
3
10
Trip current(A)
All
0.5
0.75
0.85
1
1.25
1.5
2
2.5
3.25
3.75
4.5
5.5
6.75
8
9.25
10
12.5
Trip time(s)
All
4.5
4.8
5
5.2
5.5
5.8
6
6.3
7.5
8
9
10
12
Rmax(Ω)
All
0.25
0.3
0.4
0.5
0.6
0.65
0.7
0.9
1
1.6
2
3
3.5
4
7
7.5
9
Rmin(Ω)
All
0.05
0.1
0.15
0.2
0.3
0.4
0.45
0.5
0.75
1
1.45
1.5
1.9
2.5
Pdtyp(W)
All
0.8
1
1.5
1.8
2
2.2
2.5
It(A)
All
0.2
0.3
0.34
0.4
0.5
0.6
0.8
1
1.3
1.5
1.8
2.2
2.7
3.2
3.7
4
5
Package
All
DIP
Inner Diagram Data sheet
HL130-010 0.1 130 3 0.5 6 9 2.5 0.8 0.2 DIP HL130-010
HL130-010
HL130-015 0.15 130 3 0.75 5.5 7.5 2.5 0.8 0.3 DIP HL130-015
HL130-015
HL130-017 0.17 130 3 0.85 5.2 7 1.5 0.8 0.34 DIP HL130-017
HL130-017
HL130-020 0.2 130 3 1 5 4 1.9 0.8 0.4 DIP HL130-020
HL130-020
HL130-025 0.25 130 3 1.25 4.8 3.5 1.45 1 0.5 DIP HL130-025
HL130-025
HL130-030 0.3 130 3 1.5 4.5 3 1 1 0.6 DIP HL130-030
HL130-030
HL130-040 0.4 130 3 2 4.5 2 0.75 1 0.8 DIP HL130-040
HL130-040
HL130-050 0.5 130 3 2.5 5 1.6 0.5 1 1 DIP HL130-050
HL130-050
HL130-065 0.65 130 10 3.25 5.2 1 0.45 1 1.3 DIP HL130-065
HL130-065
HL130-075 0.75 130 10 3.75 5.5 0.9 0.4 1 1.5 DIP HL130-075
HL130-075
HL130-090 0.9 130 10 4.5 5.8 0.7 0.3 1.5 1.8 DIP HL130-090
HL130-090
HL130-110 1.1 130 10 5.5 6.3 0.65 0.2 1.8 2.2 DIP HL130-110
HL130-110
HL130-135 1.35 130 10 6.75 7.5 0.6 0.15 1.8 2.7 DIP HL130-135
HL130-135
HL130-160 1.6 130 10 8 8 0.5 0.1 2 3.2 DIP HL130-160
HL130-160
HL130-185 1.85 130 10 9.25 9 0.4 0.1 2 3.7 DIP HL130-185
HL130-185
HL130-200 2 130 10 10 10 0.3 0.1 2.2 4 DIP HL130-200
HL130-200
HL130-250 2.5 130 10 12.5 12 0.25 0.05 2.5 5 DIP HL130-250
HL130-250
 1
